Description

When it’s time to make recording history, you need the best audio interface you can get – and you need one you can count on. That’s why we’re kicking it up a notch with the amazing UM2, an ultra-compact 2 x 2, 48 kHz USB interface with a studio-grade XENYX Mic Preamp, combination XLR/TRS input for your vocal and direct instrument input (no DI required) and an additional ¼ " Instrument Input. The rich feature-set, which also boasts a powerful Phones Output for the Direct Monitoring of your session, plus 2 Outputs and USB-supplied power – makes the UM2 the best, and most-portable recording interface in its class.



Features

You take your tracks seriously, and the UM2 respects them too, providing 48 kHz resolution, for the amazingly-detailed and pristine recording quality your music deserves.



Specifications

SUPPORTED SAMPLE RATES

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

MICROPHONE INPUTS

Frequency Response

20Hz - 20kHz ± 0.1dB

Dynamic Range

111dB (A-weighted)

THD+N

<0.0012%

Noise EIN

-128dBu (A-weighted)

Maximum Input Level

9dBu (at minimum gain)

Gain Range

56dB

Impedance

3kΩ

LINE INPUTS

Frequency Response

20Hz - 20kHz ± 0.1dB

Dynamic Range

110.5dB (A-weighted)

THD+N

<0.002%

Maximum Input Level

22dBu (at minimum gain)

Gain Range

56dB

Impedance

60kΩ

INSTRUMENT INPUTS

Frequency Response

20Hz - 20kHz ± 0.1dB

Dynamic Range

110dB (A-weighted)

THD+N

<0.03%

Maximum Input Level

12.5dBu (at minimum gain)

Gain Range

56dB

Impedance

1.5MΩ

LINE/MONITOR OUTPUTS

Dynamic Range (Line Outputs)

108dB

THD+N

<0.002%

Maximum Output Level (0 dBFS)

15.5dBu

Impedance

430Ω

HEADPHONE OUTPUTS

Dynamic Range

104dB (A-weighted)

THD+N

<0.002%

Maximum Output Level

7dBu

Impedance

<1Ω
