  • Description
    • The BX8-D3 studio monitors are the most powerful BX8s to date, with 150W of Class A/B bi-amplified analogue power, they are more powerful than any of the previous BX speaker models. Capable of louder volumes with less distortion, these speakers are ideal for professionals, beginners, and anyone in between who requires monitors that deliver an accurate response at any volume.
    • he M-Audio BX8-D3 features a military-grade Kevlar woofer boasting a rigid and lightweight construction, and delivering outstanding transient response whilst preventing detrimental "cone breakup." The BX8-D3 also features a treated silk dome tweeter, providing the perfect combination of low mass and negation of unwanted audible resonance.
    Features
    • Bi-amplified design with 150 watts of RMS power for powerful and accurate sound
    • 8'' Kevlar low-frequency driver with a high-temperature voice coil and damped rubber surround
    • The 1.25'' natural silk tweeter provides astounding transient details
    • New computer-optimized tweeter waveguide delivers precise imaging
    • Acoustic Space Control enables you to fine-tune the low-end response to your listening space
    • Optimized rear port provides extended low-frequency response
    • 1/4'' balanced/unbalanced and XLR balanced inputs allows you to connect to audio interfaces, mixers, synthesizers, DJ gear and more
    • Volume control enables you to dial in the ideal monitor playback level for your session or space
    • Exceptional frequency response with a wide range of 37Hz to 22kHz to cover a full musical spectrum
    • Handy front panel LED enables perfect positioning of monitor angle in relation to your listening position

    Specifications

    • Monitor Type: 2-Way Near-Field Studio Reference Monitor
    • Low Frequency Driver: 8'' (203mm) Kevlar Curved Cone with High Temperature Voice Coil & Damped Rubber Surround. Magnetically Shielded
    • High Frequency Driver: 1.25'' (32mm) Magnetically Shielded Natural Silk Dome
    • Frequency Response: 37Hz - 22kHz
    • Crossover Frequency: 1.9kHz
    • Low Frequency Amplifier Power: 85W
    • High Frequency Amplifier Power: 75W
    • Maximum Peak SPL: 110dB
    • Input Sensitivity: 85mV Pink Noise Input Produces 96dBA Output SPL at 1 meter with volume control at maximum
    • Input Connectors:
    • 1 x XLR Balanced
    • 1 x TRS Balanced/Unbalanced
    • Input Impedance:
    • 10kOhm Balanced
    • 20kOhm Unbalanced
    • Polarity: Positive Signal at + Input Produce Outward Low Frequency Cone Displacement
    • Protection:
    • RF Interference
    • Output Current Limiting
    • Over Temperature
    • Turn On/Off Transient
    • Subsonic Filter
    • External Mains Fuse
    • Voltage:
    • 100 - 120V, 50/60Hz
    • 220 - 240V, 50/60Hz
    • Power Consumption: 150W

    • Fuse:
    • 100 - 120V: T2AL 250V
    • 220 - 240V: T1AL 250V
    • Cabinet: Vinyl-Laminated High-Acoustic-Efficiency MDF
    • Dimensions (W x D x H): 9.8'' x 11.9'' x 15.1'' / 250mm x 302mm x 384mm
    • Weight: 23.1lbs / 10.5kg
