Description

• The NT1 is supplied with the revolutionary new RODE SMR shock mount. Featuring a unique double-Lyre suspension system, the SMR enhances the existing superior vibration cancellation of Rycote's Lyre system by using a smaller inner Lyre to act as a tension-ing element. This maintains each Lyre in the neutral position where it is most efficient at cancelling vibration. The SMR's removable all-metal pop filter is as effective as it is visually striking, providing an integrated solution for plosive protection that is easily washable and designed to last as long as the shock mount and microphone.

Features

• Large capsule (1") with gold-plated membrane
• Cardioid polar pattern
• Internal Rycote Lyre based capsule shock mounting system
• Ultra-low noise transformerless circuitry
• State-of-the-art surface mount electronics
• Heavy-duty matte black finish
• Gold plated output connectors
• Designed & manufactured in Australia
• SMR shock mount (NT1-KIT)

Specifications

• Acoustic Principle: Pressure Gradient
• Active Electronics: JFET impedance converter with bipolar output buffer
• Directional Pattern: Cardioid
• Frequency Range: 20Hz 20kHz
• Output Impedance: 100 Ohm
• Equivalent Noise: 4.5 dBA SPL (as per IEC651)
• Maximum Output: +8 dBu (1kHz, 1% THD into 1K Ohm load)
• Sensitivity: -29 dB re 1V/Pa (35mV @ 94dB SPL) +/2dB @ 1kHz
• Dynamic Range: 128 dB SPL
• Maximum SPL: 132 dB SPL
• Signal / Noise: 90 dBA SPL (as per IEC651)
• Power Requirements: 24V phantom power, 48V phantom power
• Output Connection: 3 Pin XLR
• Balanced output: between pin 2 (+), pin 3 (-) and pin 1 (ground)
